Basic Info.
Model NO.
SW-PA-1375014500-50C
Operating Frequency
13.75-14.5GHz
Psat Output Power
20 dBm
Vswr
1.5
RF Connectors Input/out
SMA/N
Transport Package
Carton
Specification
350*280*40 mm
Trademark
SWT
Origin
China
Production Capacity
3000 / 3 Months
Product Description
Solid State High Power RF Amplifier 50W SMA-F Connectors
ELECTRICAL SPECIFICATIONS@25˚C
| PARAMETER | MIN | TYP. | MAX | UNIT |
| Operating Frequency | 13750 | 14500 | MHz | |
| RF INPUT | 0 | dBm | ||
| P-sat Power Output | 50 | dBm | ||
| Power Gain | 50 | dB | ||
| Power Gain Flatness | ±1 | dB | ||
| Harmonic Signals | -30 | dBc | ||
| IM3@Two-tone Test,Po=41dBm (Single Carrier Level) Δ f=5MHz(IM3) | -25 | dBc | ||
| Input VSWR | 1.5 | 2 | ||
| Operating Voltage | 24 | V DC | ||
| Currents | 32 | A | ||
| In-Out impedance | 50 | Ω |
ENVIRONMENTAL RATINGS
| PARAMETER | MIN | MAX | UNIT |
| Operating Temp. (Housing Temp.) | -20 | +55 | °C |
| Humidity Range | 0-100 | % | |
| PA Baseplate Shutoff Temperature | + 85 | °C | |
MECHANICAL SPECIFICATIONS
| PARAMETER | VALUE | UNIT |
| Dimensions (L x W x H) | 350*280*40 | mm |
| RF Connectors (Input / Output) | SMA- KFD/ N- KFD | -- |
| DC / Control Connector | D-SUB 7W2 | -- |
| Cooling | Consider heat dissipation with the system | -- |
| Mounting | φ3-8 Thru Hole | -- |
| Weight | ≤10 | kg |
| INPUT/OUTPUT PINS | |||
| AMPLIFIER CONNECTOR TYPE: | D-SUB 7W2 | ||
| TRIAD CABLE PART NUMBER: | -- | ||
| PIN NUMBER | LABEL | DESCRIPTION | |
| 1-2 | +VDC | +24V | |
| 3 | GND | Ground | |
| 4 | NC | NC | |
| 5 | Amp Enable | Disable: TTL "Low", Enable : TTL "High" (Low : 0~0.5V, High : 2.5~5V) | |
| 6-9 | GND | Ground | |
Nanjing Shinewave Technology Co., Ltd. is a company specializing in the research and development, production and sales of RF microwave antennas, active and passive components and subsystems. The company's product field covers a variety of microwave communication devices, including anti-jamming antennas, RF power amplifiers, T/R modules, VCO/DROs, microwave filters, duplexers, frequency sources, and related subsystems, which are widely used in mobile communications, radar, and other fields.
In order to meet the special needs and higher requirements of customers, in addition to standard products, we provide customized product development methods. We always provide the customers with fast and high-quality products and services.
In order to meet the special needs and higher requirements of customers, in addition to standard products, we provide customized product development methods. We always provide the customers with fast and high-quality products and services.
Q&A:
Q1. Could I get a sample before bulk order?
Yes, we offer the sample for all models but charged.
Q2. What should I do if I don't know about frequency in my country?
Please feel free to contact us with your inquiry, we will find the frequency you need and offer help to your problems.
Q3. Do you accept OEM/ODM order?
Yes, we can customize the brand logo, colors, and frequencies.
Q4.Shipment Date
| Sample | 20 business days |
| ≤50 pcs | 60 business days |
| >50 pcs | 90 business days |
| >200 pcs | Negotiate |
Q5: Delivery Date of the sample by DHL/FedEx
| USA/Canada/Europe/Asia | 3-5 days |
| Middle East/Latin American | 5-7 days |
| African | 3-7 days |
