Basic Info.
Model NO.
1550nm direct modulatin transmitter
Dimensions
483(L)*380(W)*44(H)mm
Laser Type
Dfb Laser
Operation Temperature
-10~+55
DC Supply
DC Adapter
Dispersion Compensation Distance
Below 20km or Below 50km
Supply Voltage
AC 110V-250V(50Hz)
Optical Connector
Sc/APC, FC/APC
Transport Package
Standard Package
Specification
1310nm Direct Modulation AGC Optical Transmitter
Trademark
DAYTAI
Origin
China
Production Capacity
1200 Piece/Pieces Per Month
Product Description
★Description
1550nm direct modulatin transmitter,Wavelengtn:1550±10nm,Frequency range:47-862/1003MHz,Output optical power:10mW,Dispersion compensation distance:≤20KM or ≤50KM,CN:≥51dB,CTB:≤65dB,CSO:≤60dB,AGC control range:±5dB,MGC control range:0-20dB,optical fiber connector:FC/APC or SC/APC,Supply voltage:AC 110V-250V(50Hz),Dimension:483mm(L)×380mm(W)×44mm(H).American standard plug or European standard plugs is optional.
★Specification
Item | Unit | Technique Parameters | |
Output optical power | mW | 10 | |
Optical wavelength | nm | 1550±10 (have to be ITU wavelength when with inter-cut function) | |
Dispersion compensation distance | Km | ≤50 | |
Laser type |
| DFB laser | |
Optical modulation mode |
| Direct optical intensity modulation | |
Optical connector type |
| FC/APC or SC/APC | |
Frequency range | MHz | 47-862/1003 | |
RF input level | dBuV | 75-85 | |
Flatness in band | dB | ±0.75 | |
RF input impedance | Ω | 75 | |
Input return loss | dB | ≥ 16 | |
C/CSO | dB | ≥ 60 | 25Km optical fiber, 0dB received |
C/CTB | dB | ≥ 65 |
|
C/N | dB | ≥ 51 |
|
AGC control range | dB | ±5 | |
MGC control range | dB | 0-20 | |
Supply voltage | V | AC 110V-250V (50Hz) | |
Consumption | W | 30 | |
Operating temperature | ºC | 0 -- 45 | |
Storage temperature | ºC | -20 -- +65 | |
Relative humidity | % | Max 95% no condensation | |
Dimension | mm | 483(L)×380(W)×44(H) | |
