Basic Info.
Model NO.
ACME800-100A/HFP
Voltage Regulating Mode
Width Modulation Type
Power Supplying System
Terminal Power Distribution Equipment
Energy Transmission
Two-way Transmission
Modulation System
PWM
Certification
CE, ISO
Brand
Acme
Input
220V/380V
Input Mode
1 Phase 2 Wires/3 Phase 4 Wires
Control Mode
PWM
Power
10va-800kVA
Start
Soft Start
Output Voltage
0-800VDC
Output Current
0-100A
Load Change Rate
0.5%
Efficiency
90%
Frequency
0.1Hz-100Hz/100Hz-3kHz/3kHz-30kHz/5kHz-50kHz
Duty Cycle
0-100%
DC Output
Pure DC Output
Auto Reverse
Can Be Set Time
External Control
RS485/Modbus/RS232
Working Mode
CV and Cc
Transport Package
Wood Packing
Specification
80kw
Trademark
ACME
Origin
Jinan
HS Code
8504401990
Production Capacity
200PCS/Month
Product Description
Product introduction
ACME series high frequency switching pulse power supply is ACME independently developed and produced, a new high-quality, wide voltage, low noise dedicated power supply. Its superior performance can not only meet your various electrolytic, electroplating, electropolishing, electro-flocculation, electrophoresis, electro-coloring and other power supply requirements, but also through its unique high-frequency pulse rectangular wave and efficient power-saving performance for your production to create greater profits, for society to save more energy. Compact and scientific structure design, can be convenient and flexible installation, advanced space voltage, current vector control algorithm, CV, CC mode selection to ensure your control requirements, overvoltage, undervoltage, overcurrent, overtemperature, EMI suppression, fault locking and display and other functions to ensure the safety of the system operation and maintenance convenience
In accordance with international standards for design and testing to ensure the reliability of the product.
ACME series digital multi-function pulse power supply is our company developed a new high-quality, wide voltage, wide frequency, low noise special pulse power supply. This product has positive pulse, negative pulse, proportional pulse, interval pulse, counting pulse and other functions, pulse width 1us-999ms, proportional value 1-0.000001, interval quantity 1-999, pulse count 1-998001 its superior performance can not only meet your various chemical research, precision electrolysis, precision electroplating , surface modification, electrocorrosion, electrocoloration, capacitor aging, plasma discharge, radar positioning and other requirements, through its unique standard pulsed rectangular wave and high-precision regulation for your production or research to create greater benefits, saving more energy for society. Compact and scientific structure design, easy and flexible installation, advanced space voltage, current vector control algorithms, ultra-wide range and convenient frequency and pulse width adjustment, CV or CC mode selection to ensure your control requirements; overvoltage, undervoltage, overcurrent, overtemperature EMI, SUPPRESSION, Fault locking and display functions ensure the safety and maintenance of the system, according to international standards for design and testing, to ensure the reliability of the product.
ACME series FM pulse power supply is based on many years of work experience combined with the user's various working conditions to launch a high-quality pulse power supply, fully applicable to a variety of users. This product has positive pulse, negative pulse, timing pulse and other functions, timing range 1S-999H, duty cycle 1-99%, frequency range 0.1HZ-20KHZ, frequency accuracy 10HZ, voltage range 6-30KV optional, led digital meter, one-click start function, Master-to-master control mode, etc. Its control method is simple, the parameters can be adjusted in real time, can meet the user's various chemical research, a variety of water treatment, electro-corrosion, electro-coloring, capacitor aging, plasma injection and other power supply requirements, through its unique standard pulse rectangular wave and high-precision regulation can create greater benefits for your production or research, saving more energy for society. Compact and scientific structure design for easy and flexible installation, advanced space voltage, current vector control algorithms, regulatory or steady flow mode selection to ensure your control requirements, overvoltage, undervoltage, overcurrent, overtemperature, IGBT failure, fault protection selection, fault locking and display ensure the safety and maintenance of the system.
ACME series intelligent pulse power supply is based on many years of work experience combined with the user's various working conditions to launch a high-quality pulse power supply, fully applicable to a variety of users. This product has positive pulse, negative pulse, proportional pulse, interval pulse, counting pulse, timing pulse, program pulse and other functions, pulse width 1us-999ms, proportional value 1-0.000001, interval number 1-999:1-999, pulse counting 1-998001, Timing range 1-998001S, duty cycle 1-99%, frequency range 1HZ-100KHZ, frequency accuracy 1HZ, 5 segment program pulse optional, per segment program pulse running time 1-998001S, voltage range 6-30KV optional, current range 1-30KA optional, user-friendly display interface, Pointer and digital display mode, one-click start function, master-to-master control mode, etc. Its superior performance not only can meet your various chemical research, a variety of water treatment, vacuum coating, vacuum sputtering, precision electrolysis, precision plating, surface modification, electrocorrosion, electrocoloration, capacitive aging, plasma injection and other requirements for power supply, through its unique standard pulsed rectangular waves and high-precision regulation can create greater benefits for your production or research, saving more energy for society. Compact and scientific structure design for easy and flexible installation, advanced space voltage, current vector control algorithms, CV or CC mode selection to ensure your control requirements, overvoltage, undervoltage, overcurrent, overtemperature, IGBT failure, fault protection selection, Fault locking and display functions to ensure the safety and maintenance of the system operation, 7-inch touch screen control, perfect status and parameter display interface with multi-functional input and output port, more centralized monitoring function of the upper machine so that the user's production control process to achieve perfect intelligence. Design and test in accordance with international standards to ensure the reliability of the product.
Sewage electrocoagulation power supply
The reaction principle of electrocoagulation is that aluminum, iron and other metals are used as anode. Under the action of direct current, the anode is dissolved and Al, Fe plasma is produced,
In a series of hydrolysis, polymerization, and oxidation of ferrous iron,various hydroxyl complexes, polynuclear hydroxyl complexes and hydroxides have been developed,separate the colloidal impurities, suspended impurities, and precipitate in the waste water,Simultaneous,the charged particles travel in the electric field, and some of the charges are neutralized by electrodes to make them stable and concentrated.
When the wastewater is treated with electrolytic flocculation, it can not only precipitate and precipitate colloidal impurities and suspended impurities, but also can remove a variety of pollutants in the water due to the oxidation of the anode and the reduction of the cathode.
After years of research and field test, our company has developed a sewage electrocoagulation power supply which can accelerate ion polarization, shorten flocculation time, reduce plate consumption, prevent plate passivation, and reduce power consumption. Widely used in electrocoagulation, electro oxidation, electricity Fenton, electrical demulsification, electrical sterilization and other sewage treatment projects.
ACME series high frequency switching pulse power supply is ACME independently developed and produced, a new high-quality, wide voltage, low noise dedicated power supply. Its superior performance can not only meet your various electrolytic, electroplating, electropolishing, electro-flocculation, electrophoresis, electro-coloring and other power supply requirements, but also through its unique high-frequency pulse rectangular wave and efficient power-saving performance for your production to create greater profits, for society to save more energy. Compact and scientific structure design, can be convenient and flexible installation, advanced space voltage, current vector control algorithm, CV, CC mode selection to ensure your control requirements, overvoltage, undervoltage, overcurrent, overtemperature, EMI suppression, fault locking and display and other functions to ensure the safety of the system operation and maintenance convenience
In accordance with international standards for design and testing to ensure the reliability of the product.
ACME series digital multi-function pulse power supply is our company developed a new high-quality, wide voltage, wide frequency, low noise special pulse power supply. This product has positive pulse, negative pulse, proportional pulse, interval pulse, counting pulse and other functions, pulse width 1us-999ms, proportional value 1-0.000001, interval quantity 1-999, pulse count 1-998001 its superior performance can not only meet your various chemical research, precision electrolysis, precision electroplating , surface modification, electrocorrosion, electrocoloration, capacitor aging, plasma discharge, radar positioning and other requirements, through its unique standard pulsed rectangular wave and high-precision regulation for your production or research to create greater benefits, saving more energy for society. Compact and scientific structure design, easy and flexible installation, advanced space voltage, current vector control algorithms, ultra-wide range and convenient frequency and pulse width adjustment, CV or CC mode selection to ensure your control requirements; overvoltage, undervoltage, overcurrent, overtemperature EMI, SUPPRESSION, Fault locking and display functions ensure the safety and maintenance of the system, according to international standards for design and testing, to ensure the reliability of the product.
ACME series FM pulse power supply is based on many years of work experience combined with the user's various working conditions to launch a high-quality pulse power supply, fully applicable to a variety of users. This product has positive pulse, negative pulse, timing pulse and other functions, timing range 1S-999H, duty cycle 1-99%, frequency range 0.1HZ-20KHZ, frequency accuracy 10HZ, voltage range 6-30KV optional, led digital meter, one-click start function, Master-to-master control mode, etc. Its control method is simple, the parameters can be adjusted in real time, can meet the user's various chemical research, a variety of water treatment, electro-corrosion, electro-coloring, capacitor aging, plasma injection and other power supply requirements, through its unique standard pulse rectangular wave and high-precision regulation can create greater benefits for your production or research, saving more energy for society. Compact and scientific structure design for easy and flexible installation, advanced space voltage, current vector control algorithms, regulatory or steady flow mode selection to ensure your control requirements, overvoltage, undervoltage, overcurrent, overtemperature, IGBT failure, fault protection selection, fault locking and display ensure the safety and maintenance of the system.
ACME series intelligent pulse power supply is based on many years of work experience combined with the user's various working conditions to launch a high-quality pulse power supply, fully applicable to a variety of users. This product has positive pulse, negative pulse, proportional pulse, interval pulse, counting pulse, timing pulse, program pulse and other functions, pulse width 1us-999ms, proportional value 1-0.000001, interval number 1-999:1-999, pulse counting 1-998001, Timing range 1-998001S, duty cycle 1-99%, frequency range 1HZ-100KHZ, frequency accuracy 1HZ, 5 segment program pulse optional, per segment program pulse running time 1-998001S, voltage range 6-30KV optional, current range 1-30KA optional, user-friendly display interface, Pointer and digital display mode, one-click start function, master-to-master control mode, etc. Its superior performance not only can meet your various chemical research, a variety of water treatment, vacuum coating, vacuum sputtering, precision electrolysis, precision plating, surface modification, electrocorrosion, electrocoloration, capacitive aging, plasma injection and other requirements for power supply, through its unique standard pulsed rectangular waves and high-precision regulation can create greater benefits for your production or research, saving more energy for society. Compact and scientific structure design for easy and flexible installation, advanced space voltage, current vector control algorithms, CV or CC mode selection to ensure your control requirements, overvoltage, undervoltage, overcurrent, overtemperature, IGBT failure, fault protection selection, Fault locking and display functions to ensure the safety and maintenance of the system operation, 7-inch touch screen control, perfect status and parameter display interface with multi-functional input and output port, more centralized monitoring function of the upper machine so that the user's production control process to achieve perfect intelligence. Design and test in accordance with international standards to ensure the reliability of the product.
Sewage electrocoagulation power supply
The reaction principle of electrocoagulation is that aluminum, iron and other metals are used as anode. Under the action of direct current, the anode is dissolved and Al, Fe plasma is produced,
In a series of hydrolysis, polymerization, and oxidation of ferrous iron,various hydroxyl complexes, polynuclear hydroxyl complexes and hydroxides have been developed,separate the colloidal impurities, suspended impurities, and precipitate in the waste water,Simultaneous,the charged particles travel in the electric field, and some of the charges are neutralized by electrodes to make them stable and concentrated.
When the wastewater is treated with electrolytic flocculation, it can not only precipitate and precipitate colloidal impurities and suspended impurities, but also can remove a variety of pollutants in the water due to the oxidation of the anode and the reduction of the cathode.
After years of research and field test, our company has developed a sewage electrocoagulation power supply which can accelerate ion polarization, shorten flocculation time, reduce plate consumption, prevent plate passivation, and reduce power consumption. Widely used in electrocoagulation, electro oxidation, electricity Fenton, electrical demulsification, electrical sterilization and other sewage treatment projects.
| Item | High frequency pulse power supply | FM pulse power supply | Multi-function pulse power supply | Intelligent Pulse power supply |
| Model | ACME-V/HFP | ACME-V/FM | CTDP-V/MFP | CTNP-V/IPP |
| Voltage range | 6-10000V | 6-3000V | 6-3000 | 6-3000V |
| Current range | 1-20000A | 1-10000A | 1-10000A | 1-10000A |
| Frequency range | 30-45KHZ | 0.1-20KHZ | 1HZ-100KHZ | 1HZ-100KHZ |
| Duty cycle range | 1-90% | 1-99% | ***** | 1-99% |
| Pulse width range | ***** | ***** | 1Us-999mS | 1US-999mS |
| Servo mode | CV,CC manual change | CV,CC manual change | CV,CC manual change | CV,CC manual change |
| Adjust mode | Duty cycle adjust | Positive and negative pulse amplitude, duty cycle adjust | Positive and negative pulse amplitude, pulse width adjust | Positive and negative pulse amplitude, duty cycle, pulse width adjust |
| Control mode | Touch buttons/knob control/Electronic shift (Optional) | Touch buttons/knob control | Touch buttons/knob control | Full touch screen control/knob control |
| Communication | Analog, 485(optional) | Analog, 485(optional) | ***** |
