Basic Info.
Packaging & Delivery
Product Description
| Name | Battery Swapping Type Dock Tractor | ||
| Brand / Series | CAMC / Electric battery swapping type dock tractor | ||
| Drive type | 4x2 | ||
| Wheel base(mm) | 3800 | ||
| Quasi-tow mass(kg) | 34865 | ||
| Kerb Weight (kg) | 9500 | ||
| Rated GVW/ GVW (kg) | 6805/18000 | ||
| Overall dimension (mm) | 5915x2495x3200 | ||
| CAB | |||
| Type | CAMC M5 concrete mixer | ||
| Color | Standard color: red, yellow, blue, white; others: optional but charge | ||
| Parameter | With two berth,Berth curtain,Leather 4-spoke Steering Wheel,Rear window,electronic and Hydraulic reversal cab,power window, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, heating & ventilation system, adjustable roof flap, with stereo radio and MP3, and adjustable steering wheel, air horn, single berth with 4-point support fully floating suspension and shock absorber with transverse stabilizer, safety belt. | ||
| Others | A/C, radio,MP3, one sleeper, curtain etc. | ||
| ENGINE | |||
| Supplier | CAMC-The Chinese most advanced truck Engine Producer | ||
| Model |
| ||
| Type | Four-troke, water-cooled, in-line, wet-liner, direct-injection | ||
| Maximum power/horsepower(kw/hp) | 254/345 | ||
| Maximum rated speed(rpm) | 1900 | ||
| Max torque(N.m/rpm) | 1660/1100-1400 | ||
| Cylinders | 6 | ||
| Bore x Stroke (mm) | 118*150 | ||
| Displacement (L) | 9.84 | ||
| Controller type | Electrical | ||
| Air cleaner | Dry paper element | ||
| Emission Standard | Euro V | ||
| TRANSMISSION | |||
| Supplier | CAMC | ||
| Model | 9SDB2051A | ||
| Type | Mechanical & manual with servo & Synchronizer & creep | ||
| Speed ratio | 9 forward ratio:15.49, 12.07,8.35,5.67,4.07,2.96,2.05,1.39,1.00 | ||
| 1 reverse ratio:14.19 | |||
| CLUCH | |||
| Type | Single- plate dry diaphragm spring clutch, diameter 430(A) mm, hydraulically operating with air assistance | ||
| Plate diameter | 430mm | ||
| STEERING SYSTEM | |||
| Driving position | Left or Right hand drive available | ||
| Type | hydraulic steering with power assistance | ||
| Ratio | 22.2-26.2:1 | ||
| Supplier | CAMC | ||
| Front axle | CAMC technology steering axle with double T-cross section, Rated capacity:7.5T | ||
| Rear axle | CAMC technology 16T casting axle , with double reduction and differential locks between axles, Rated capacity:16T | ||
| ratio: 4.10 | |||
Service according to your requirements
1. Who are we?
We are based in Anhui, China, start from 2017,sell to Domestic Market(58.60%),Africa(10.00%),Southeast Asia(10.00%),South Asia(5.00%),South America(5.00%),Eastern Europe(3.00%),Mid East(3.00%),Central America(3.00%),Oceania(1.00%),North America(1.00%),Eastern Asia(0.10%),Southern Europe(0.10%),Northern Europe(0.10%),Western Europe(0.10%). There are total about 51-100 people in our office.
2. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available.
3. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
4. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
5: Can you produce customized goods ?
A: Yes, the size, diameter and length can be produced as per client's requirements.
6. why should you buy from us not from other suppliers?
CAMC is the national priority production and research development base of heavy truck, special purpose heavy vehicle and spare parts, which is also the state mainly supports enterprise.
7. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
