DVB-T 2 CH Modulator to Convert with HDMI Input 2 Route Input Modulator

Introducing our DVB-T 2 CH Modulator to Convert with HDMI Input 2 Route Input Modulator. We are a factory specializing in high-quality audio/video equipment.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
WS-7992
Transport Package
Carton Packing
Specification
280mm(L) × 203mm(W) × 61mm(H)
Trademark
SATLINK
Origin
China
HS Code
9030401000
Production Capacity
5000

Product Description

WS-7992 DVB-T modulator is developed to adapt terrestrial digital television. It's mainly applied in home entertainment, surveillance control, hotel Digital Signage, shops etc. And it is integrating MPEG-4 AVC/H.264 encoding and modulating to convert audio/video signals into DVB-T RF out.



 FEATURES

  • High level of integration, high-performance, Full-featured, integrated design

  • 2 route input modulator that converts analogue A/V source to a DVB-T

    channel

  • Standard COFDM modulation and H.264 encoding

  • Multiple video format compatibility including 576i(PAL) / 480i(NTSC) / 1080p

  • Bandwidth: 6/7/8MHz

  • Frequency range: 50~860MHz

  • Continuously adjustable RF signal output level range 70dBuV from 100dBuV,

    step 1dBuV

  • 2.4-inch color LCD display

  • Small size and light weight

  • Carriers 2K and 8K

  • User friendly setup and control

  • Compact and wall mountable


    TECHNICAL SPECIFICATION

    Modulator

    Standard

    DVB-T

    Constellation

    QPSK / 16QAM / 64QAM

    Bandwidth

    6 / 7 / 8 MHz

    Carriers

    2K / 8K

    Guard Interval

    1/4, 1/8, 1/16, 1/32

    Code Rate

    1/2, 2/3, 3/4, 5/6, 7/8

    MER

    35 dB

    Frequency Range

    50 ~ 860 MHz

    Output Level

    70 ~ 100 dBuV

    Output Impedance

    75Ω

    Video

    Input Format

    CVBS/HDMI

    Encoding Format

    H.264

    Video Resolution

    576i PAL / 480i NTSC/1080p

    Connector

    RCA/HDMI 1.3

    Audio

    Input Format

    Stereo L/R channel

    Encoding Format

    MPEG-1 Audio Layer II

    Connector

    RCA

    General

    Power Source

    DC 12V / 1.5A

    Operating Temperature

    0 ~ +50°C

    Dimensions

    280mm(L) × 203mm(W) × 61mm(H)

    Weight

    1.26Kg

DVB-T 2 CH Modulator to Convert with HDMI Input 2 Route Input Modulator DVB-T 2 CH Modulator to Convert with HDMI Input 2 Route Input Modulator DVB-T 2 CH Modulator to Convert with HDMI Input 2 Route Input Modulator DVB-T 2 CH Modulator to Convert with HDMI Input 2 Route Input Modulator
