Basic Info.
Supply Voltage
+ 15V DC
The Working Frequency
1MHz-1000MHz
Input and Output Impedance
50 Ohms
The Maximum Output Range
35dBm
The Input Signal Size
0dBm--2dBm
Gain
35 dB
Transport Package
Standard Packing
Specification
8.00X4.00X2.00 cm
Trademark
SWT
Origin
Nanjing, China
HS Code
8518400090
Production Capacity
10000PCS/3 Months
Product Description
GSM Network LTE 2g 3G 4G RF Module WCDMA Power Amplifier 2110-2170 Jam Signal RF Repeater 10W Professional RF Power Amplifier
Power amplifier size 37MMx56CMx1.5CM (behind with a large heat sink)
1. Supply voltage: + 15V DC (typical current value 450mA / maximum gain output)
2. The working frequency: 1MHZ-1000MHZ, input and output impedance: 50 ohms;
3. The maximum output range: 35dbm (3W / 50 ohms)
4. Gain: 35 dB (see the specific curve S21 curve, there are differences between different frequency)
5. The input signal size: low frequency board (0DBM / 1 mW), high frequency board (2DBM)
Nanjing Shinewave Technology Co., Ltd. is a company specializing in the research and development, production and sales of RF microwave antennas, active and passive components and subsystems. The company's product field covers a variety of microwave communication devices, including anti-jamming antennas, RF power amplifiers, T/R modules, VCO/DROs, microwave filters, duplexers, frequency sources, and related subsystems, which are widely used in mobile communications, radar, and other fields.
In order to meet the special needs and higher requirements of customers, in addition to standard products, we provide customized product development methods. We always provide the customers with fast and high-quality products and services.
This board RF power amplifier, suitable for all kinds of radio, FM radio remote control toy, radio and so on, the input of 1 MW (0DBM) maximum output of 3 watts, 15V voltage power supply, board 1MHZ to 1000MHZ can work. Because of the excellent design, in low frequency can reach 35DBM (3W), when 500M the output power can reach 32DBM (1.6W).
Power amplifier size 37MMx56CMx1.5CM (behind with a large heat sink)
1. Supply voltage: + 15V DC (typical current value 450mA / maximum gain output)
2. The working frequency: 1MHZ-1000MHZ, input and output impedance: 50 ohms;
3. The maximum output range: 35dbm (3W / 50 ohms)
4. Gain: 35 dB (see the specific curve S21 curve, there are differences between different frequency)
5. The input signal size: low frequency board (0DBM / 1 mW), high frequency board (2DBM)
Nanjing Shinewave Technology Co., Ltd. is a company specializing in the research and development, production and sales of RF microwave antennas, active and passive components and subsystems. The company's product field covers a variety of microwave communication devices, including anti-jamming antennas, RF power amplifiers, T/R modules, VCO/DROs, microwave filters, duplexers, frequency sources, and related subsystems, which are widely used in mobile communications, radar, and other fields.
In order to meet the special needs and higher requirements of customers, in addition to standard products, we provide customized product development methods. We always provide the customers with fast and high-quality products and services.
