High Speed High Accuracy Macinte Food Grade Conveyor Machine Checkweigher

Find the perfect High Speed High Accuracy Macinte Food Grade Conveyor Checkweigher at our factory. Our machines ensure fast and accurate product weighing.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Description
  • Details Images
  • Product Advantage
  • Other Models
  • Certifications
  • Company Profile
Overview

Basic Info.

Model NO.
MXTH-TG1-03
Touch Screen
Touch Screen
Sorting Method
Pusher-bar
Certificate
CE
Material
304 Stainless Steel
Weighing Speed
20~180pieces/Min
Color
Silver
Transport Package
Plywood Packing
Specification
140*68*145cm
Trademark
Macinte
Origin
China
HS Code
8423302000
Production Capacity
100 Sets/Month

Product Description

Hight Speed High Accuracy Macinte Checkweigher Scale Sorting Conveyor Machine with Rejector

Provide below information to our sales , our team will support you to choose the right type checkweigher:
Tested product
1. Size range: min and max size

2, Weight range: min and max weight
3, Accuracy requirements: +_ g.

4, Speed requirements: pcs/min;


Product Description

High Speed High Accuracy Macinte Food Grade Conveyor Machine Checkweigher

Main equipment parameters
Model MXTH-22-03-S
Structure Component Speed up section + Weighing section + Rejector section
Speed up conveyor belt section size 240mm (L) *130mm (W) (can be customized)
Weighing section conveyor belt size 240mm(L)*130mm(W)
Reject section
conveyor belt size
460mm(L)*130mm(W)(can be customized)
Height ( weighing belt to ground) 700mm±50mm,(can be customized)
Control system NXP 32-bit Dual-core ARM High-speed High-performance Embedded System (independently developed)
Conveyor speed m/min 15~75m/min(Adjustable)
highest speed pc/min 0-100 pcs/min (Related with item length, spacing and precision requirements)
Weighing range 5g~300g
Weighing accuracy g ±0.1g (Precision is related with product size, weight and state, through the volume and working environment vibration and wind)
Minimum display g 0.1g
Preset product parameter Number (formula) 100
Data storage Mode USB export
Power AC100-240V,50HZ/60HZ
Rated power 180W
Working environment -10-45ºC,90%R.H
Machine body material Whole machine 304 stainless steel
Machine size(mm) 975*580
Machine weight kg About 90 KG
Main configuration
Touch screen Highlight, high resolution, 8 inch color touch screen
Weighing sensor USA  SUNCELL Precision sensor
Weighing module MXT-AD Macinte independent research and development of patented products
Motor Brushless motor   precision machining, concentricity, position accuracy, high transmission efficiency, bearing capacity
Photoelectric sensor Japan panasonic The photoelectric switch of the opposite light, the accuracy is higher, guarantee no leakage
Control switch IDEC Emergency start switch, exquisite technology, long working life
Weighing belt White or blue food grade PU conveyor belt
Motor belt USA GATES Synchronous belt drive, long service life;
Bearing Japan NSK  High precision, small vibration, durable
Roller Hard oxide three waist drum aluminum alloy belt roller, automatic correction, wear - resistant skid
Details Images



High Speed High Accuracy Macinte Food Grade Conveyor Machine Checkweigher
Whiteshell3-coplor belt buzzing alarm lamp, simple and elegant appearance aesthetic and practical.

High Speed High Accuracy Macinte Food Grade Conveyor Machine Checkweigher
Using up and down photolectric sensor installation method for thin materiaIs to ensure accuracy,no miss detection.

High Speed High Accuracy Macinte Food Grade Conveyor Machine Checkweigher
Original AIRTAC pneumatic units durable,good aftermarket.

Product Advantage

1) Independent intellectual property rights, stable and mature technology.
2) First-class workmanship, professional mechanical design.
3) Good environmental adaptability and stability.
4) Key parts are imported.
5) Safety protection.
6) Accurate and efficient sorting mechanism.
7) Data storage and export and system integration.
8) Power off memory function.
9) Automatic mean sampling function.
10) Humanized operation interface.
11) Simple user Settings.
12) One-key parameter recovery function.
13) Remote assistance function.
14) Optional and customized automation scheme.

Other Models


High Speed High Accuracy Macinte Food Grade Conveyor Machine Checkweigher

High Speed High Accuracy Macinte Food Grade Conveyor Machine Checkweigher

Certifications

High Speed High Accuracy Macinte Food Grade Conveyor Machine Checkweigher

Company Profile

Shenzhen Macinte has More than 20 Years of Weighing Industry Experience

We are the only enterprise to obtain the invention patent of
"weighing identification method and system" issued by the State Intellectual Property Office.

Service for a number of the world's top 500 enterprises, domestic listed companies, and widely praised, well known at home and
abroad.


Shenzhen Macinte Intelligent Equipment Co., Ltd. was founded in 2002, which is a national high-tech enterprise, shenzhen
high-tech enterprise, shenzhen double soft enterprise. Main products include automatic weight checking devices, weight testing
machine, weigher sorting machine, online weighing and culling machine, pick to light system, line shaft diverter system, DWS
system, logistics conveying control system, etc. We have marketing centers, R&D centers and production bases in ShenZhen and
ChangSha.Our company has an expert team composed of a number of doctors, field application engineers, etc., long-term focus on
algorithm research, application development, industrial applications, has obtained a number of national invention patents. We aim
at "professional casting quality, scientific and technological achievements future" ,and walking in the technical front.

High Speed High Accuracy Macinte Food Grade Conveyor Machine Checkweigher



High Speed High Accuracy Macinte Food Grade Conveyor Machine Checkweigher
