Basic Info.
Model NO.
AW-D615
Materials and Colors
3.8ABS, White
Certification
TUV
Operating Voltage
3VDC(with Battery 6f22)
Operating Temperature
10ºC~55ºC,Relative Humidity: ≤95%
Application
3.5for Indoor Use Only
Alarm Level
≥85dB@3 M and ≥93dB@1m
Size
105mm*105mm*43mm
Transport Package
Carton Box
Specification
10*10*0.3
Trademark
Guta
Origin
China
HS Code
8539490000
Production Capacity
20000PCS/Month
Product Description
The detector is a photodetector that uses the most advanced optical sensing chamber. The detector is designed to provide open area protection without wiring and easy to install and construct;
The red LED on each detector provides a local 360° visible alarm indication. They flash once every minute, indicating that the power is on and the detector is working. When an alarm occurs, the red LED is on; when the battery is low, the red LED will flash and will beep.
The red LED on each detector provides a local 360° visible alarm indication. They flash once every minute, indicating that the power is on and the detector is working. When an alarm occurs, the red LED is on; when the battery is low, the red LED will flash and will beep.
The red LED will be on when the fire alarm is activated, until the smoke concentration is lower than the alarm threshold.
The test button is used to test whether the detector works normally; each time the buzzer is pressed, the buzzer emits a beep, the red LED flashes, and simulates a fire alarm; this button can be used for local mute during a fire.
The test button is used to test whether the detector works normally; each time the buzzer is pressed, the buzzer emits a beep, the red LED flashes, and simulates a fire alarm; this button can be used for local mute during a fire.
Features
* Easy to install, mounting bracket included
* High quality durable sensor
* Loud 85dB alarm and LED
*warning indicator
* Excellent reliability and highstability
* Suitable for all families and other places where needs
Meets all requirements of latest EN14604 standard
| Model | AW-D615 |
| Operating Voltage | 3VDC(with battery CR123 ) |
| Operating current | monitoring status≤8uA, alarm status≤20mA |
| Smoke Alarm Sensitivity | 0.18-0.30dB/m |
| Smoke Alarm | ≥85dB @3 |
| Low battery alarm voltage | ≤2.4V |
| Battery life | ≥10 Years |
| Indicator | Normal: blinking Alarm: lighting |
| Environmental | Temperature range: -10 to 55°C (14~131°F) Humidity: 5 to 95% RH, non-condensing |
| Materials and colors | ABS, white |
| Size | 105mm * 41mm (with cover) |
| Weight | About 120G |
