Basic Info.
Model NO.
DW-FTIR-530A
Advantage
High Resolution
Principle
Classic Spectrometer
Wavelengths
Infrared Spectrometer
Dispersive Element
Grating Spectrometer
Light Number
Monochromator
Certification
RoHS, ISO9001, CE
Customized
Customized
Spectral Range
7800 to 350 Cm-1
Resolution
Better Than 0.85cm-1
Signal to Noise Ratio
Better Than 20,000:1
Detector
Room Temperature Dlatgs Module
Wavelength Accuracy
0.01 Cm-1
Scanning Speed
Microprocessor Control, Different Scanning Speed S
Software
Main Ftos Suite Software Workstation
Beam Splitter
Multilayer Ge Coated Kbr
Interferometer
Cube-Corner Michelson Interferometer
Standard Accessory
Transmission Sample Holder
Optional Accessory
Gas Cell, Liquid Cell, Atr, etc.
Transport Package
Wood Carton
Specification
54*52*26cm
Trademark
Drawell
Origin
Shanghai
HS Code
9027809900
Production Capacity
10000/Month
Product Description
DW-FTIR-530A FTIR SPECTROMETER
FTIR Spectrometer DW-FTIR-530A with fully independent intellectual property rights. Adhering to consistent excellent quality and superior performance, the new model obtains the best balance between intelligence and convenient operation, advance performance and low operation and maintenance cost. It is a good choice for basic science research analysis, production quality control,testing and detection in various fields.
Features:
1. High sensitivity and stability
2. Intelligent real-time monitoring of instrument status
3. Multiple communication options
4. Flexible and convenient testing
5. Powerful software workstation
| Interferometer | Cube-corner Michelson interferometer | |
| Beam splitter | Multilayer Ge coated KBr | |
| Detector | Room temperature DLATGS module (standard) | Temperature stabilized, high sensitivity DLATGS module (optional) |
| IR Source | High intensity, long lifetime, air-cooled IR source | |
| Wavenumber Range | 7800cm-1~350cm-1 | |
| Resolution | 0.85 cm-1 | |
| Signal to noise ratio | Better than 20,000:1 (RMS value, at 2100cm-1 ~ 2000cm-1 or 2100cm-1 ~ 2200cm-1, resolution: 4cm-1, detector: DLATGS, 1 minute data collection) | |
| Wavenumber Accuracy | ±0.01 cm-1 | |
| Scanning Speed | Microprocessor control, different scanning speed selectable. | |
| Software | MainFTOS Suite software workstation, compatible to all version Windows OS | Various specialized functional software modules (optional) |
| Communication | Ethernet interface (standard) | WIFI wireless communication (optional) |
| Data Output | Standard data format, report generation and output | |
| Status Diagnosis | Power on self check, real-time temperature and humidity monitoring and reminders | |
| Certification | IQ/OQ/PQ(Optional) | |
| Environment Conditions | Temperature: 10ºC~30ºC, humidity: less than 70% | |
| Power Supply | AC220V±22V,50Hz±1Hz | AC110V(optional) |
| Dimensions & Weight | 520 x 435 x 255mm, 24kg | |
| Accessories | Transmission sample holder (Standard) | Optional accessories such as gas cell, liquid cell, Defused/Specular Reflection, single/multi reflection ATR, etc. |
