Laser Pulse Compression Diffraction Nir Volume Phase Holographic Transmission Gratings

LaserPulseTech: Leading factory for advanced laser products including compression, diffraction, holographic transmission gratings, and more. Expert in volume phase optics.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
TT Grating-12
Shape
Single-lens
Material
Optical Glass
Lenses Color
Clear
Certification
ISO9001
Customized
Customized
Coating
HMC
Min
1 Unit
Payment Term
L/C, T/T, D/P, Western Union, Paypal, Money Gram
Thickness
as Required
Surface Quality
40-20 or Better
Bevel
Protective Bevel as Needed Products Learn More
Diameter Tolerance
+0/-0.01 or as Required
Transport Package
Carton, Blister, Customized
Specification
As required
Trademark
TT
Origin
Tianjin
HS Code
9001909090
Production Capacity
4000pieces/Month

Packaging & Delivery

Package Size
10.00cm * 10.00cm * 18.00cm
Package Gross Weight
1.000kg

Product Description

Laser Pulse Compression Diffraction NIR Volume Phase Holographic Transmission Gratings

D iffraction gratings
Diffraction gratings are used to separate light into component wavelengths, are offered in both transmission and reflective varieties for use from the UV to the MIR. Our diffraction grating selection includes ruled (blazed), volume phase holographic, holographic, echelle, and a grating modulator.

NIR Volume Phase Holographic Transmission Grating

  • Five Design Wavelengths from 840 nm to 1300 nm
  • High First-Order Diffraction Efficiency
  • Resistant to Fingerprint and Aerosol Damage

Features

  • Design Wavelength (DWL) and Spatial Frequency Options:
    • 840 nm: 1200 Lines/mm
    • 900 nm: 1000 Lines/mm
    • 930 nm: 900, 1200, or 1500 Lines/mm
    • 1030 nm: 800 or 1800 Lines/mm
    • 1300 nm: 800 Lines/mm
  • High First-Order Diffraction Peak Efficiency (See Tables Below)
  • Uniform Performance Over Broad Bandwidths (See Diffraction Efficiency Graphs Below)
  • Extremely Low Scatter Between Orders (No Ghosting)
  • Dichromated Gelatin (DCG) Film Between Two Glass Substrates
  • Ideal for Spectroscopy, Optical Coherence Tomography (OCT), and Laser Pulse Compression
Near Infrared Volume Phase Holographic (VPH) Transmission Gratings are ideal for applications that require high diffraction efficiency.
Laser Pulse Compression Diffraction Nir Volume Phase Holographic Transmission Gratings
Common Specifications
Grating Film Dichromated Gelatin
Cover-Plate Substrate GP3508P and GP1118P:
C7980 Fused Silicaa or Equivalent
All Others: N-BK7a or Equivalent
Thickness Tolerance ±0.2 mm
Spatial Frequency ±2 lines/mm
Tolerance
AOI Tolerance ±1°
Transmitted Wavefront <λ/4 at 632.8 nm
Error (RMS)
Surface Quality 40-20 Scratch-Dig
Selection Guide
Transmission Gratings
Ruled UV
Visible
Near IR
Volume Phase Visible
Holographic Near IR
Reflective Gratings
Ruled UV
Visible
Near IR
Mid IR

Laser Pulse Compression Diffraction Nir Volume Phase Holographic Transmission Gratings
Manufacturing accuracy of lenses or according to customer's need
Laser Pulse Compression Diffraction Nir Volume Phase Holographic Transmission Gratings
Inspections
Laser Pulse Compression Diffraction Nir Volume Phase Holographic Transmission Gratings Laser Pulse Compression Diffraction Nir Volume Phase Holographic Transmission Gratings
Application field
Laser Pulse Compression Diffraction Nir Volume Phase Holographic Transmission GratingsLaser Pulse Compression Diffraction Nir Volume Phase Holographic Transmission GratingsLaser Pulse Compression Diffraction Nir Volume Phase Holographic Transmission GratingsLaser Pulse Compression Diffraction Nir Volume Phase Holographic Transmission Gratings
