Basic Info.
Model NO.
RF Receiver PCB
Application
Consumer Electronics
Flame Retardant Properties
V0
Mechanical Rigid
Rigid
Processing Technology
Electrolytic Foil
Base Material
Copper
Insulation Materials
Organic Resin
Brand
Finestpcb
Service
One-Step PCB Service
Solder Mask Color
Blue.Green.Red.Black.White
Layer
1-40layers
Min BGA Ball Pitch
0.4mm
Surface Finishing
HASL\OSP\Immersion Gold
HASL\OSP\Immersion Gold
Fr4/Rogers/Aluminum/High Tg
Copper Thickness
0.5-5oz
Board Thickness
1.6 ±0.1mm
Minimum Hole
Minimum
Minimum Width
3/3mil
Minimum Line
3/3mil
Product Name
OEM PCB PCBA Board Assembly
Transport Package
Vacuum Package for Bare PCB and ESD Package
Specification
customized
Trademark
finest
Origin
China
HS Code
8534001000
Production Capacity
30000 Pieces
Packaging & Delivery
Package Size
10.00cm * 10.00cm * 5.00cm
Package Gross Weight
1.000kg
Lead Time
10 days (1 - 10 Pieces)
To be negotiated ( > 10 Pieces)
To be negotiated ( > 10 Pieces)
Product Description
Product Title: Elevate Connectivity with Our RF Receiver PCB
Experience connectivity like never before with our state-of-the-art RF Receiver PCB. Engineered for excellence, this PCB opens the door to a world of seamless communication and superior signal reception.
Product Benefits:
Precision Reception: Unleash the power of precise signal reception for flawless communication.
Expanded Range: Connect confidently over extended distances with our RF Receiver PCB's impressive range capabilities.
Energy Efficiency: Efficient power management ensures prolonged battery life, maximizing device performance.
Product Features:
Product Specifications:
Superior Material: Crafted with high-quality FR-4 for durability and reliability.
Frequency Range: Optimized for 1MHz - 6GHz applications.
Impedance Mastery: Maintains a stable 50 Ohms for consistent performance.
Layer Count: 4 layers for enhanced signal processing.
Key Features:
Gold-Plated Contacts: Ensures corrosion resistance for enduring reliability.
Compact Design: Ideal for space-conscious applications.
RoHS Compliant: Aligns with environmental standards for responsible manufacturing.
Upgrade your devices with our RF Receiver PCB, where cutting-edge technology meets unmatched reception capabilities. Trust in a connected world with seamless communication at the heart of your electronic experience.
Why choose Finest PCB Assembly?
FAQ
Experience connectivity like never before with our state-of-the-art RF Receiver PCB. Engineered for excellence, this PCB opens the door to a world of seamless communication and superior signal reception.
Product Benefits:
Precision Reception: Unleash the power of precise signal reception for flawless communication.
Expanded Range: Connect confidently over extended distances with our RF Receiver PCB's impressive range capabilities.
Energy Efficiency: Efficient power management ensures prolonged battery life, maximizing device performance.
Product Features:
Product Specifications:
Superior Material: Crafted with high-quality FR-4 for durability and reliability.
Frequency Range: Optimized for 1MHz - 6GHz applications.
Impedance Mastery: Maintains a stable 50 Ohms for consistent performance.
Layer Count: 4 layers for enhanced signal processing.
Key Features:
Gold-Plated Contacts: Ensures corrosion resistance for enduring reliability.
Compact Design: Ideal for space-conscious applications.
RoHS Compliant: Aligns with environmental standards for responsible manufacturing.
Upgrade your devices with our RF Receiver PCB, where cutting-edge technology meets unmatched reception capabilities. Trust in a connected world with seamless communication at the heart of your electronic experience.
Why choose Finest PCB Assembly?
1. More than 19 years experience of in electronic manufacturing services for PCB making.
2. One-stop service | PCB Manufacturing | Components sourcing and PCB assembly one-stop PCBA service to help you easily achieve your electronic products.
3. More than 1000 customers working with us for telecom, IOT, RF, smart control, security, medical, industrial, automotive, 3G / 4G / 5G products.
4. Reasonable and stable price: have established a strong global electronics components supply chain that helps us get
reasonable and stable price
reasonable and stable price
5. Quality assurance: more than 15 years of experience in the engineering team and quality control team to ensure
all products come out under control.
6. Professional replace-solution: help customers source professional replace-solution to achieve faster, lower cost with high-quality components purchasing agent service.
all products come out under control.
6. Professional replace-solution: help customers source professional replace-solution to achieve faster, lower cost with high-quality components purchasing agent service.
| PCBA Technical Capability | |
| 1. Assembly Type:: | FR4, FPC, Rigid-flex PCB, Metal base PCB. |
| 2. Assembly Specification: | Min size L50*W50mm; Max size: L510*460mm |
| 3. Assembly thickness: | Min thickness: 0.2mm; Max thickness: 3.0mm |
| 4. Components Specification | |
| Components DIP: | 01005Chip/0.35 Pitch BGA |
| Minimum device accuracy: | +/-0.04mm |
| Minimum footprint distance: | 0.3mm |
| 5. File format: | BOM list; PCB Gerber file: |
| 6. Test | |
| IQC: | Incoming inspection |
| IPQC: | Production inspection; first ICR test |
| Visual QC: | Regularly quality inspection |
| SPI test : | Automatic solder paste optical inspection |
| AOI: | SMD component welding detection, components shortage & component polarity detection |
| X-Ravd: | BGA test; QFN and other precision devices hidden PAD device inspection |
| Function test: | Test function and performance according to the customer's test procedures and steps |
| 7. Reworking: | BGA rework equipment |
| 8. Delivery Time | |
| Normal delivery time: | 24 hours( fastest 12 hours quick-turn) |
| Small production: | 72 hours( fastest 24 hours quick-turn) |
| Medium production: | 5 working days. |
| 9. Capacity: | SMT assembly 5 million points/day; plug-in & welding 300,000 points/day; 50-100 items/day |
| 10. Components Service | |
| A full set of substitute materials: | Have experience in component procurement sourcing, and management systems, and provide cost-effective services for OEM projects |
| Only SMT: | Do SMT and backhand welding according to components PCB boards provided by customers. |
| Components purchasing: | Customers provide core components, and we provide component sourcing services. |
| PCB Specification: | |||||
| PCB layers: | 1-24layers | ||||
| PCB materials: | CEM1, CEM3, Rogers, FR-4, High Tg FR-4, Aluminum Base, Halogen Free | ||||
| PCB max. board size: | 620*1100mm (Custom) | ||||
| PCB certificate: | RoHS Directive-Compliant | ||||
| PCB Thickness: | 1.6 ±0.1mm | ||||
| Layer Copper Thickness: | 0.5-5oz | ||||
| Inner Layer Copper Thickness: | 0.5-4oz | ||||
| PCB max. board thickness: | 6.0mm | ||||
| Minimum Hole Size: | 0.20mm | ||||
| Minimum Line Width/Space: | 3/3mil | ||||
| Min. S/M Pitch: | 0.1mm(4mil) | ||||
| Plate Thickness and Aperture Ratio : | 30:1 | ||||
| Minimum Hole Copper: | 20µm | ||||
| Hole Dia. Tolerance(PTH): | ±0.075mm(3mil) | ||||
| Hole dia. Tolerance(NPTH): | ±0.05mm (2mil) | ||||
| Hole Position Deviation: | ±0.05mm (2mil) | ||||
| Outline Tolerance: | ±0.05mm (2mil) | ||||
| PCB solder mask: | Black, white, yellow | ||||
| PCB surface finished: | HASL Lead-free, Immersion ENIG, Chem Tin, Flash Gold, OSP, Gold finger, Peelable, Immersion Silver | ||||
| Legend: | White | ||||
| E-test: | 100% AOI, X-ray, Flying probe test. | ||||
| Outline: | Rout and Score/V-cut | ||||
| Inspection Standard: | IPC-A-610CCLASSII | ||||
| Certificates: | UL (E503048),ISO9001/ISO14001/IATF16949 | ||||
| Outgoing Reports: | Final Inspection, E-test, Solderability Test, Micro Section, and More | ||||
