Th1773 DC Bias Current Source Frequency Bandwidth 50Hz-200kHz

https://ckt2017.en.made-in-china.com/product-list-1.html

Features

MPU control
20×2 large character LCD display with backlight
Frequency bandwidth: 50 Hz - 200 kHz
0 to 10A current output, max power output 90 W
Directly controllable by TH2816A
Low additional error , wide frequency bandwidth
Auto or manual current sweep output
Single, multi and equal interval current output modes
DC current output with forward or reverse
0 to 99s delay time setup
Long time high current output available
Optional GPIB and RS232C interface
ser control setting memory
Strong protective design against damage of LCR meter

Brief Introduction
TH1773 is a DC Bias Current Source (or DC Magnetization
Current Source) used for inductance measurement of inductors
and transformer windings with DC bias current. Except
for constant current output, low additional error and wide
frequency bandwidth are important for bias current inductance
measurement. High frequency LCR meter could be used, when
the frequency bandwidth is wide enough. MPU controlled auto
current balance technology is adopted to realize AC+DC current
overlap and constant current output from 0 to ±10A.TH1773 With
its low additional error, wide frequency response bandwidth and
sweep output function is widely used in DC biased inductance
measurement. It also provides a perfect solution for magnetic
material analysis.
