Product Description
| Projects | Specifications |
| Winding Type | Star |
| Hall Effect Angle | 120° electrical angle |
| Shaft Axial Play | 0.025mm |
| Ambient Temperature | -20~ + 50°C |
| Ambient Humidity | <80% |
| Max. Radial Force | 75N@20mm from the flange |
| Max. Axial Force | 20N |
| Insulation Class | Class B |
| Dielectric Strength | one minute@500VAC |
| Insulation Resistance | 100MΩMin.@500VDC |
| Model | Rated Voltage | Rated Torque | Rated Speed | Rated Current | Rated Power | Peak Torque | Torque Constant | Body Length | Weight |
| VDC | N.M | RPM | A | W | N.M | N.M/A | MM | KG | |
| 57BL60-230 | 24 | 0.2 | 3000 | 3.5 | 62 | 0.6 | 0.057 | 60 | 0.6 |
| 57BL60-215 | 24 | 0.2 | 1500 | 1.7 | 31 | 0.6 | 0.118 | 60 | 0.6 |
| 57BL80-230 | 24 | 0.4 | 3000 | 7 | 126 | 1.2 | 0.057 | 81 | 1 |
| 57BL80-215 | 24 | 0.4 | 1500 | 3.5 | 62 | 1.2 | 0.114 | 81 | 1 |
| 57BL100-230 | 24 | 0.6 | 3000 | 10.4 | 188 | 1.8 | 0.057 | 102 | 1.4 |
| 57BL100-215 | 24 | 0.6 | 1500 | 5.2 | 94 | 1.8 | 0.115 | 102 | 1.4 |
Please feel free to contact us for more details.
| Stepper motor | Brushless motor | Synchronous motor |
Changzhou Sino-pan Electric Co., Ltd. is an export-oriented enterprise. Located in Xinbei District, Changzhou City, Jiangsu Province, China. After years of operation, the scale of our enterprise has continued to expand. Gradually grow into a group company. At present, our company mainly produces automotive bulbs (such as halogen bulbs and automotive LED bulbs/as well as household LEDs and commercial LEDs), motors (brushless motors/stepping motors/synchronous motors/asynchronous motors). At the same time, we are also appointed by many clients as purchasing and quality inspection agents in China.
We provide you with high-quality, fast, efficient and inexpensive automotive lighting, motors and auxiliary electrical services. Zhongpan welcomes your patronage with a smile, and we will provide you with a variety of satisfactory products and a full range of consulting services. We firmly believe that the cooperation with us will be infinitely better! Strive to create a stronger tomorrow for our customers!
Q1. Can I provide sample orders for your products?
A: Of course, you can check our quality before ordering. If you have any requirements, please contact us.
Q2. What is your delivery time?
A: It depends on the order quantity. Usually, it takes about 3-7 days after receiving the small deposit. Bulk ordering takes 10-20 days.
Q3. What kind of customers and what kind of companies do you work with?
A: We have 20 years of export experience and serve more than 100 customers, such as retailers, wholesalers, and online store owners.
Q4. Is it possible to put our logo on your product or product packaging?
A: Of course, we have a factory, welcome to customize your brand, LOGO, color, product manual, packaging, etc.
Q5: Can you OEM for me?
A: We accept all OEM orders, just contact us and give me your design. We will provide you with a reasonable price and make samples for you as soon as possible.
Q6: What are your payment terms?
A: According to T/T, LC AT SIGHT, 30% deposit in advance, and the balance 70% before shipment.
